Terex Manlift Specifications
Based in Westport, Connecticut, Terex specializes in manufacturing construction machinery. They manufacture machines like aerial lifts, manlifts and boom lifts. These kinds of machinery are designed to facilitate access to places that are difficult to reach, roofs and buildings, large equipment, among other things. A manlift, as defined by the U.S. Occupational Safety and Health Administration or also called OSHA refers to a power-driven endless belt. This belt moves just in one direction and includes handholds or platforms or steps which are connected to the unit to be able to transport personnel from each floor.
TB85
Terex's TB85 man lift provides a max working height at 91 feet. The platform's max height reaches 85 feet, while the model's maximum width is 8.5 feet. The TB85 has dimensions measuring 9 inches wide and 9 feet, 1-inch high by 36 feet. This particular model provides a reach of 70 feet. The TB85 has a boom angle above horizontal reaching 75 degrees and below horizontal measures at -14 degrees.
Terex TB100
The maximum height of Terex's TB100 man lift is 106 feet and the maximum height of the platform is 100 feet. The TB100 when stowed away, is about 8.5 feet wide by 9 feet high by 8 feet. The unit's maximum width is 8 feet, 1 1/2 inches. The boom angle below horizontal is -14 degrees and above horizontal is 75 degrees. The horizontal reach measures at 67 feet, 4 inches.
TB110
The Terex TB110 man lift reaches a max height of 100 feet, whilst the max working height measures at 116 feet. The model is 8 feet wide x 9 feet, 4 inches high The TB110 offers a horizontal reach of 67 feet and a maximum width of 8 feet. This particular model has a boom angle of 75 degrees above horizontal plus ten degrees articulating. It measures -105 degrees articulating and below horizontal it is -14 degrees.
